Ducted Walk-In Fume Cupboards
Ducted Walk-In fume cupboards from HFH are available in a variety of standard sizes from 1200mm wide upwards.
Ducted Walk-In Fume Cupboards
Step into the World of Safe Science: Explore Ducted Fume Cupboards!
2 Models of ducted walk-in fume cupboards are available the standard and the radius profile. Standard sizes are 1200 1500 1800 and 2000 mm wide. None standard sizes can be manufactured on request
STANDARD ANGLE SIDED FUME CUPBOARDS
The Standard fume cupboard is a high quality, robust design of ducted fume cupboard at a competitive price,
Performance and Safety
Certified to BS EN 14175.
Technical and Design
- Twin-skin shell in distinctive styling and a choice of colours and finishes.
- Sprung PVC guide channels for directional stability with smooth rise and fall sash action.
- High Sash version available to suit customer requirements.
Features
- Fire resistant twin skin shell.
- Choice of mechanical and electrical services.
- Choice of worktop materials if required
- Choice of lining materials.
- Sinks and drip cups available in a full range of sizes.
- Sash handle profile designed to improve containment within the work chamber and reduce eddies.
- Aerodynamically designed.
- Interior chamber smooth and easy to clean and maintain.
- Unique sash locking device for operator protection.
- Adjustable baffles to ensure optimum containment levels on site.
- Factory pre-plumbed and pre-wired for rapid on-site connection.
- 6mm thick toughened glass sash.
- Sash counterbalance using double stainless steel cables and ball race pulleys of the fail-safe design.
HIGH PERFORMANCE RADIUS PROFILE FUME CUPBOARD
The Radius Profile Fume Cupboard significantly enhances performance.
The smooth curved inlet delivers ultra-containment by eliminating air eddies in the chamber. Independent testing has confirmed the highest level of containment currently claimed by any fume cupboard manufacturer, with a Robustness of Containment Protection Factor (PFR) of >4,500,000 for all widths at 0.5 m/s face velocity.
The Radius Profile fume cupboard is ideal for projects with large quantities of mechanical and electrical services. The robust design is engineered to outlast contemporary fume cupboards.
Performance and Safety
Certified to BS EN 14175, exceeds proposed UK Band 1 recommended values.
Features
- Fire resistant twin skin shell
- Increased viewing height
- Increased chamber height
- Unique flush membrane control panel, easy to wipe down
- BROEN Water and Gas services
- Full access, removable service panels and upper hinged panels for periodic maintenance and inspection
- State of the art appearance and a choice of colours
- 316-grade stainless steel tissue guards to prevent debris being drawn into the fan unit
- Sash handle profile designed to improve containment within the work chamber and reduce eddies
Controls
A touch button control panel assures maximum control for fan switching and provides safety features at your finger-tips. Alarms for air velocity, sash high and fan operation ensure your cabinet is always operating to maximum protection.
Alarm levels are reported on the display and activate a buzzer. Optional volt-free contacts may be used for remote monitoring of cabinet.
